Main Features：
● Adopt large screen touch screen operation display, easy to understand operation and setting;
● Equipped with memory function, which can store many kinds of operation procedures;
● Intelligent control, grinding time can be controlled, time and speed can also be set and displayed;
● High reproducibility of grinding results;
● fast grinding and homogenization with short grinding time, which can be used for XRF analysis with high processing capacity of rapid sample preparation;
● dual jar grinding and the availability of high throughput grinding for biological samples;
● For most materials it takes only a few tens of seconds to grind, mix and homogenize the sample.
● Using titanium alloy bearings enables continuous operation for a long time.
Techncial Parameters：
Model | HMD-400 |
Item Number | 1019009001 |
Features | Crushing ,grinding ,mixing and homogenizing |
Sample type | Hard,soft,brittle,elastic,hydrated,fibrous |
Put in sample size(mm) | 40 |
Out sample size(μm) | about 5-10 |
Batch capacity(ml) | ＜2x50 |
Grinding time(min) | 1-3 |
Grinding mode | Dry grinding, wet grinding, low temperature grinding, high throughput grinding |
Grinding tank qty | 2 |
Grinding tank category | Screw-cap tanks (various material options) |
Shaking speed(r/min) | 180-2100 |
Frequency(Hz) | 3-35 |
Crushing time(h) | 0-8h：00m：00s |
Power(W) | 250 |
Instrument size L*W*H(mm) | 490*400*312 |
Packing size L*W*H(mm) | 640*525*475 |
