Product Features
● Simple and convenient operation, large display screen;
● 4.3 inch TFT capacitive screen display, man-machine friendly touch operation interface;
● All icons are displayed dynamically, which is more user-friendly;
● Automatic fault detection and buzzer alarm function, temperature deviation calibration function;
● The transparent insulation cover is made of high temperature resistant PC environ mental protection material, integrated design to prevent loss, built-in over-temperature protection device, multiple safety protection functions, composite CE safety standards, safe and reliable;
● Optional USB or PC communication function.
Technical Parameters
Model | HICE-4 |
Temperature Range | -10~100℃ |
Display Mode | 4.3 inch high-definition capacitive screen |
Control mode | Full screen TFT touch |
One-button 4°C constant temperature function | Yes |
Work or fault alarm prompt function | Yes |
Temperature calibration function | Yes |
Temperature dynamic display function | Yes |
Computer or host computer control | Optional USB interface |
Power Supply | 100-240V/50-60HZ~1.0A |
Time Set | / |
Temperature control accuracy | ≤ ± 0.5 ℃ |
Display accuracy | 0.1 ℃ |
Module temperature uniformity | ≤ ± 0.3 ℃ |
Heating time | ≤15min（20℃ to 100℃） |
cooling time | ≤10min （RT 25℃ to 4℃） |
Standard centrifuge tube module | 35*2.0ml |
Optional centrifuge tube module | A,B,C,D,E,F,G,H,J,K,L,M,N |
Temperature control method | semiconductor |
input power | 250W |
fuse | 250V 3A Ф5×20 |
Dimensions (mm) | 280(L)×210(W)×180(H) |
Packaging size (mm) | 340(L)×265(W)×235(H) |
Net weight/gross weight (kg) | 3.5/4.5 |
